2. The commuter is always aware of the latest sales promotion and community

information.

The end user will benefit from the hourly weather forecast.

The Block Diagram of the Pre-paid Local-Traffic card

Figure C 1

Functionality:

• If the cardholder presses the button once then the CPU will pass a control signal that

will display the static timetable, which is stored in a reserved partition of the memory.

• If the cardholder presses the button second time in the RF range then the CPU will

activate the RFID Chip to get the dynamic information from the nearest bus stop i.e.

weather forecast, bus status information (delay/on time and empty/full), community

information etc.

• Pressing the button the third time will enable sales promotion information.

Note: If the user is not in the RF range only static timetable will be displayed.

SpecificationTablefortheCard

Required Components Available Components Suggested Components

Screen

Technology

Dimensions: 70 mm by

50 mm by 150 um

Resolution:

XGA 768x1024

Colour screen

Refresh rate: Maximum

0.1 s

Gyricon, E-Ink,

Bridgestone,

Liquavista, Fujitsu,

P-Ink, BiNem, Sipix

E-Ink, Bridgestone,

Sipix, BiNem-color

Battery Dimension: Maximum

50 mm by 45 mm by

0.50 mm

Supply Voltage:

Minimum 3.0 Volt

Power Supply:

Minimum 750 mW

Solicore:

(48 mm by 43 mm by

0.45 mm, 3.0 V),

LiteStar:

(25.4 mm by 25.4 mm

by 0.110 mm, 4.0 V)

LiteStar (rechargeable)

Could be charged

through the RF-power

harvester.
