D o c u m e n t N o : D 1 0 0 2 5 2

Page: 2

RapMan V3.1.0 Build Manual

Summary

This document provides instructions to fit the components from the ‘BfB 3000 Upgrade kit’. Please examine your

upgrade kit – the packs supplied in your kit dictate which upgrades you need to carry out (if an item is not included

in the upgrade kit this means your machine already has the part fitted). Match the codes supplied in your kit to the

table of contents below.

Table of Contents

Summary .................................................................................................................................................................... 2

400771 Y dead-stop .................................................................................................................................................... 3

400813 Full filament reel turntable ............................................................................................................................. 4

400821 Filament reel turntable extension ................................................................................................................... 6

400818, 400819 & 400820 Extruder motor reinforcement plate ................................................................................. 8

400822 Pressure bearing complete ........................................................................................................................... 12

400823 Pressure bearing plate and top hat ............................................................................................................... 13
